Panasonic PT-RQ25K 21,000 Lumen 4K DLP Projector

Compact Form-Factor Streamlines Workflow

PT-RQ25K Series is 40 % smaller and 35 % lighter than PT-RQ22K for easy handling and workflow. Intel® SDM-ready slot expands connectivity with proprietary or third-party function boards. Smart Projector Control app, NFC function, Remote Preview LITE, and preactivated upgrade kits for Geo Pro streamline installation.

Create an Engaging Visual Experience

Quad Pixel Drive creates smooth 4K images while newly improved Dynamic Contrast delivers higher white brightness and deep blacks during high-contrast scenes. Gradation Smoother reduces color banding, while Panasonic’s exclusive black-level adjustment evolves again to support seamlessmulti-screen projection.

Maintenance-free for Peace of Mind

Hermetically sealed optical block andhigh-efficiency liquid-cooling system enable maintenance-free projection for 20,000 hours. Multi-Laser Drive Engine and Backup Input enhance reliability for failure-proof projection. Refined power supply supports projection at up to 15,000 lm on AC 100–120 V power.

• Projector type: 3-Chip DLP™ projector
• DLP™ chip | Panel size: 20.3 mm (0.8 in) diagonal (16:10 aspect ratio)
• DLP™ chip | Number of Pixels: 2,304,000 (1920 x 1200 pixels) x 3
• Light Source: Laser diode
• Light Output: 20,000 lm / 21,000 lm (Center)
• Time until light output declines to 50%: 20,000 hours (NORMAL/QUIET), 24,000 hours (ECO)
• Resolution: 4K (3840 x 2400 pixels) (Quad Pixel Drive: ON)
• Contrast Ratio: 25,000:1 (Full On/Full Off, Dynamic Contrast [3])
• Screen size (diagonal): 1.78–25.40 m (70–1000 in), 1.78–15.24 m (70–600 in) with ET-D75LE8/ ET-D3LET80,3.05–15.24 m (120–600 in) with ET-D75LE95,5.08–15.24 m (200–600 in) with ET-D3LEU100/D3LEW200
• Center-to-corner zone ratio: 90%
• Lens shift | Vertical (From the origin point of the lens mounter): ±66 % (±52 % with ET-D75LE6/ET-D3LEW60, +71 % / +93 % with ET-D75LE95, ±66 % with ET-D3LEU100, ±57 % with ET-D3LEW200) (powered)
• Lens shift | Horizontal (From the origin point of the lens mounter): ±24 % (±18 % with ET-D75LE6/ET-D3LEW60, ±14 % with ET-D75LE95, -25 % / +30 % with ET-D3LEU100, ±18 % with ET-D3LEW200) (powered)
• Keystone Correction Range | Vertical: ±45 ° (± 40 ° with ET-D75LE10/ET-D3LEW10/ET-D75LE20/ET-D3LES20,±28 ° with ET-D75LE6/ET-D3LEW60, ±22 ° with ET-D3LEW50, ±15 ° with ET-D3LEW200, ±8 ° with ET-D3LEU100, +5 ° with ET-D75LE95)
• Keystone Correction Range | Horizontal: ±40 ° (±15 ° with ET-D3LEW50/ET-D75LE6/ET-D3LEW60, ±5 ° with ET-D3LEU100/ET-D3LEW200, 0 ° with ET-D75LE95)When [VERTICAL KEYSTONE] and [HORIZONTAL KEYSTONE] are used simultaneously, correction cannot be made exceeding a total of 55 °.
• Terminals | HDMI In: HDMI x 2 (Deep Color, compatible with HDCP 2.3, 4K/60p signal input")
• Terminals | DisplayPort: DisplayPort™ x 1 (Deep Color, compatible with HDCP 2.3, 4K/60p signal input")
• Terminals | Multi Projector Sync In: BNC x 1
• Terminals | Multi Projector Sync Out: BNC x 1
• Terminals | Serial In: D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
• Terminals | Serial Out: D-sub 9-pin (male) x 1 for link control (RS-232C compliant)
• Terminals | REMOTE 1 IN: M3 stereo mini-jack x 1 for wired remote contro
• Terminals | REMOTE 1 OUT: M3 stereo mini-jack x 1 for link control (for wired remote control)
• Terminals | Remote 2 In: D-sub 9-pin (female) x 1 for external control (parallel)
• Terminals | LAN: RJ-45 x 1 for network connection, PJLink™ (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible
• Terminals | USB: USB connector (Type A) x 1 for optional AJ-WM50 Series Wireless Module/USB memory
• Terminals | DC Out: USB Type A x 1 (for power supply, DC 5 V, 2 A)
• Terminals | Expansion Slot: Open slot for for function boards, Intel® SDM compatible
• Power Supply: AC 100 V–120 V / AC 200 V–240 V, 50 Hz/60 Hz (The maximum value of light output is limited to 15,000 lm or less when using the projector with AC 100 V to AC 120 V. Other limitations apply.)
• Power consumption | Maximum power consumption: AC 200 V–AC 240 V : 1,490 W (1,520 VA) AC 100 V–AC 120 V : 1,080 W (1,090 VA)
• Power consumption | On-mode power consumption (Operating mode) [Normal]: 1,330 W
• Power consumption | On-mode power consumption (Operating mode) [Eco]: 1,040 W
• Power consumption | On-mode power consumption (Operating mode) [Quiet]: 1,030 W
• Operation Noise: 46 dB (NORMAL/ECO), 43 dB (QUIET)
• Dimensions (W x H x D): Approx. 550 x 220 x 570 mm (21 5/8˝ x 8 11/16˝ x 22 7/16˝) (not including protruding parts)
• Weight: Approx. 35 kg (77.2 lbs)
• Operating Environment: Operating temperature: 0–45 °C (32–113 °F*9), operating humidity: 10–80 % (no condensation)
• Applicable software/application: Logo Transfer Software, Multi Monitoring & Control Software, Projector Network Setup Software, Early Warning Software, Geometry Manager Pro, Smart Projector Control for iOS/Android™
