ROE Visual Ruby 1.5mm LED Panel

Simply Stunning

Only the best is good enough. Surpassing existing technology, ROE Visual has developed the 4in1 mini LED in a 2.3 and 1.5 pixel pitch, exclusively available for Ruby. Stronger, less reflection and more contrast due to an optimized black body, the resulting colors are striking.

Cutting-Edge Common Cathode Technology

With its high-brightness LED performance, the Ruby panels give an excellent visual performance for both direct viewing and in-camera visuals. Using the common cathode technology, power consumption is reduced by 20-25%, resulting in optimum heat-dissipation. Due to this technology more brightness and less color differences in the LEDS makes the visual performance stable and brilliant.

Automatic Edge Protection

The Ruby LED panels incorporate automatic edgeprotection on each panel corner, thereby reducing pixel damage drastically. The magnet-assisted assembly and vertically operated side locks with Z-axis correction make assembly quick, accurate and easy.

Unprecedented Viewing Angle

The absence of any mask enables an unprecedented wide viewing angle. With its high-brightness LED performance, the Ruby panels give an excellent visual performance for both direct viewing and in-camera visuals.

Easy Maintenance

With both front and rear module service, the Ruby panels are easy to maintain. The
integrated PSU and Hub unit make repair and replacement of spare parts easy and cost-effective.

A Multitude of Shades of Black Coming Alive

With its improved grayscales Ruby offers precision imagery, showing black in endless scales and fluent gradients.

Details that Matter. Individual LED Lens

Each 4in1 LED supports 4 individual lenses instead of on large one. This results in a
remarkable LED performance, due to reduced glare and leads to a perfect on-camera
performance of the LED screens. The enhanced black body between the individual LEDs creates more contrast and guarantees optimum brightness.

HDR. True Colors

Sporting advanced driver ICs and LEDs with large color space, Ruby is fully HDR adaptive. Adding excellent color depth and great grayscales to your visuals.

• Pixel Pitch: 1.56mm
• Max Brightness Calibrated: 800nits
• Panel Dimension: 500mm x 500mm x 73mm | 19.7” x 19.7” x 2.87”
• Panel Resolution (H x V): 320 x 320
• Panel Weight: 8.16kg | 17.99lbs
• Power Consumption Max / Average: 210W / 105W
• BTU Max / Average: 715 / 330
• Transparency: Solid
• Serviceability: Front / Rear
• Curving (Concave & Convex): Concave 5°~Convex 3°
• Max. Hanging (panels): 20
• Max. Stacking (panels): 12
• LED Configuration: 4 in 1 common cathode
• Viewing Angle Horizontal: 140°
• Viewing Angle Vertical: 140°
• Scan Ratio: 1/16
• Refresh Rate: 3840Hz
• Gray Scale: 14bit
• Frame Material: Magnesium Alloy
• Processing Platform: MVR / Brompton
• Operational Temp / Humidity: -20°~45°C, 10~90%RH | -4°~113°F, 10~90%RH
• Storage Temp / Humidity: -40°~60°C, 10~90%RH | -40°~140°F, 10~90%RH
• IP Rating: Indoor
• Certifications: CE, ETL, FCC, RoHS, WEEE
• 3D Ready: Yes
